Horizontal line

水平线处理线

Using line development + vacuum etching + film removal online production mode, effectively improve continuous operation, reduce residual film, residual copper, etching impurity

Horizontal line1
Horizontal line2
Horizontal line3
Horizontal line4

Line making

LINE MAKING

LDI laser exposure, integrated production equipment to effectively control line small, short, etched unclean, line width and line distance up to 4mil minimum, AOI optical detection, eliminate all hidden quality problems

LDI Burst light
LINE
Large automatic etching
AOI Optical detection

Packing

包装

Automatic large vacuum packing machine ensures that each package of products can be safely delivered to customers, with an average daily shipment of up to 500 times

Packaging workshop
Packing and delivery
Packing and delivery
Packing machine

Forming

成型

In order to meet the shipping size required by customers, PCB board was CNC edging or V-CUT, and the process capacity was within 0.10mm

CNC Numerical control
Forming shop
East rig
Laser forming

Test

电路板测试

Automatic electric test or flying needle test, eliminate all open circuit, short circuit. Ensure that every piece of board delivered to the customer is a qualified product。

Test shop
Flying needle test
High speed flying needle test machine
Automatic testing machine

Tengli Electronics headquarters

PCB Production shop
